Pigment Alpha Blue 15.0

Phthalocyanine Pigment Alpha Blue is a derivative of CPC crude. Pigment Blue 15.0 is Alpha Modification of CPC Blue. It has a slight reddish blue tone.It has high tinting strength and is recommended in uses for water based dispersions, paints, rubber, plastics etc.

Mass Tone	Reduced Tone

PRODUCT DESCRIPTION

Color Index Name	PIGMENT BLUE 15.0
Color Index No.	74160
Chemical Identity	Copper Phthalocyanine Blue Alpha
CAS No.	147-14-8
Chemical Formula	C₃₂H₁₆CuN₈
Molecular Weight	575.5 mg/mol

PHYSICAL PROPERTIES

Physical Appearance	Blue Powder
pH	6.5 – 8.5
Moisture	<1%
Bulk Density	0.35 - 0.45 gm/cc
Residue on Sieve: (325 mesh)	<0.1%
Oil Absorption	30 - 40 gms oil/100 gms of pigment
Heat Stability	Stable upto 180 deg. C for 10 minutes

LIGHT FASTNESS TO (SCALE 1 – 8)

Mass Tone	8
Reduced Tone	8

RESISTANCE TO BLEED (SCALE 1-5)

Water :	5
5% Hydrochloric Acid :	5
Raw Linseed Oil :	5
Ethyl Alcohol :	5
Ethyl Acetate :	5
Xylene :	5
Methyl Ethyl Ketone :	5
Mineral Turpentine :	5
5% Soap Solution :	5

Pigment Alpha Blue 15.1

Phthalocyanine Pigment Alpha Blue is a derivative of CPC crude. Pigment Blue 15.1 an improved Alpha Modification of CPC Blue. It is the more heat stable variant of Alpha 15.0 It is highly recommended for plastic applications that require high heat stability and good dispersion.

Mass Tone	Reduced Tone

TECHNICAL DATA SHEET

PRODUCT DESCRIPTION

Color Index Name	PIGMENT BLUE 15.1
Color Index No.	74160
Chemical Identity	Copper Phthalocyanine Blue Alpha
CAS No.	147-14-8
Chemical Formula	C₃₂H₁₆N₈Cu
Molecular Weight	575.5 mg/mol

PHYSICAL PROPERTIES

Physical Appearance	Blue Powder
pH	6.5 – 8.5
Moisture	<1%
Bulk Density	0.35 - 0.45 gm/cc
Residue on Sieve: (325 mesh)	<0.1%
Oil Absorption	30 - 40 gms oil/100 gms of pigment
Heat Stability	Stable upto 280 deg. C for 10 minutes

LIGHT FASTNESS (SCALE 1 – 8)

Mass Tone	8
Reduced Tone	8

RESISTANCE TO BLEED (SCALE 1-5)

Water :	5
5% Hydrochloric Acid :	5
Raw Linseed Oil :	5
Ethyl Alcohol :	5
Ethyl Acetate :	5
Xylene :	5
Methyl Ethyl Ketone :	5
Mineral Turpentine :	5
5% Soap Solution :	5

Pigment Beta Blue 15.3

Pigment Beta Blue 15.3 is beta modification of CPC Blue. It has a slight greenish blue tone having good heat stability, good flow and tinting strength. Pigment Blue 15.3 is widely recommended for various applications like paints, inks plastics, rubber etc.

Mass Tone	Reduced Tone

TECHNICAL DATA SHEET

PRODUCT DESCRIPTION

-C32H16CuN8

Color Index Name	PIGMENT BLUE 15.3
Color Index No.	74160
Chemical Identity	Copper Phthalocyanine Blue Beta
CAS No.	147-14-8
Chemical Formula	C₃₂H₁₆CuN₈
Molecular Weight	575.5 mg/mol

PHYSICAL PROPERTIES

Physical Appearance	Blue Powder
pH	6.5 – 8.5
Moisture	<1%
Bulk Density	0.35 - 0.45 gm/cc
Residue on Sieve: (325 mesh)	<0.1%
Oil Absorption	30 - 40 gms oil/100 gms of pigment
Heat Stability	Stable upto 210 deg. C for 10 minutes

LIGHT FASTNESS (SCALE 1 – 8)

Mass Tone	8
Reduced Tone	8

RESISTANCE TO BLEED (SCALE 1-5)

Water :	5
5% Hydrochloric Acid :	5
Raw Linseed Oil :	5
Ethyl Alcohol :	5
Ethyl Acetate :	5
Xylene :	5
Methyl Ethyl Ketone :	5
Mineral Turpentine :	5
5% Soap Solution :	5

Pigment Beta Blue 15.4

Pigment Beta Blue 15.4 is an improved beta modification of CPC Blue Pigment 15.4 excellent flow properties and high solvent stability. It is highly recommend for solvent based inks.

Mass Tone	Reduced Tone

TECHNICAL DATA SHEET

PRODUCT DESCRIPTION

Color Index Name	PIGMENT BLUE 15.4
Color Index No.	74160
Chemical Identity	Copper Phthalocyanine Blue Beta
CAS No.	147-14-8
Molecular Formula	C₃₂H₁₆N₈Cu
Molecular Weight	576.07 mg/mol

PHYSICAL PROPERTIES

Physical Appearance	Blue Powder
pH	6.0 – 7.5
Moisture	<1%
Bulk Density	0.5 - 0.6 gm/cc
Residue on Sieve: (325 mesh)	<0.1%
Oil Absorption	30 - 40 gms oil/100 gms of pigment
Heat Stability	Stable upto 210 deg. C for 10 minutes

LIGHT FASTNESS (SCALE 1 – 8)

Mass Tone	8
Reduced Tone	8

RESISTANCE TO BLEED (SCALE 1-5)

Water :	5
5% Hydrochloric Acid :	5
Raw Linseed Oil :	5
Ethyl Alcohol :	5
Ethyl Acetate :	5
Xylene :	5
Methyl Ethyl Ketone :	5
Mineral Turpentine :	5
5% Soap Solution :	5
